Technology data
Voltage: AC100-240V/50-60Hz
Power: 320W
LEDs: 84pcs 3030 or 3535 white LEDs module, single LED 5W
LEDs power: 300W
LEDs life: 50000-100000 hours
Color Temp.: 3200k or 5600k
CRI:  ≥93，TLCI≥91
Luminous flux: 3200K/6430 lm、5600K/8960 lm
Beam angle: 5°
Control signal: DMX
DMX channel: 1 channel
Control model: DMX or manual button
Dimming: 16BIT above smooth flicker-free dimming, dimming not delay,  frequency 20k above.
Zooming: manual knob zoom
Radiation fan ：custom made fan , its speed and noisy changeable intelligently
Ambient temperature：-25℃-40℃
IP rating：IP20
Inner size：110X41X42cm
Packing size：118.5X49.5X49.5cm
Net weight：12kg
Gross weight：16.2kg




Beam size and LUX data at different distances

Distance（m）		8	10	12	14	16	18	20	25	30	35	40	45
Beam diameter（m）		0.7	0.87	1.05	1.22	1.4	1.57	1.75	2.18	2.62	3.06	3.49	3.93
P5A56（300W 5600K）	centre(LUX）	16225	11960	8450	6410	5060	4090	3350	2170	1590	1220	895	710
	average(LUX）	12019	8859	6259	4748	3748	3030	2481	1607	1178	904	663	526
P5A32（300W 3200K）	centre(LUX）	13680	9490	7260	5460	4475	3615	2940	1925	1400	1065	795	630
	average(LUX）	10133	7030	5378	4044	3315	2678	2178	1426	1037	789	589	467
